    3 Point Key Lock 6 Layers Moving File Cabinets Shelf System Corrosion Protection

    Ask Lasest Price
    Model Number : W-MFC2017526
    Certification : ISO9001/14001
    Price : Negotiation
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 100 SETS
    Delivery Time : 15-30 Days
    • Product Details
    • Company Profile

    3 Point Key Lock 6 Layers Moving File Cabinets Shelf System Corrosion Protection

    3-Point Key Lock 6 Layers Corrosion Protection Mobile Racking System


    Description:


    1. Mobile Racking System consists of fixed shelves installed on mobile chassis at the bottom.

    2. Every rack has its own transmission equipment.

    3. It is suitable for the storage of museum, chancery, library, hospital and bank.

    4. It has the advantage of being compact and could utilize the room adequately, fully enclosed all.

    5. Only one aisle to be used, the highest space utilization, beautiful and practical, sealing better, which can be manually and automatically operated.

    6. Widely used in archives, library, bank and company documents center, etc


    Please feel free to tell me your demands, We will try to give you the professional suggestion.The product can be customized according your using space and your drawing or layout !


    Features:

    Raw material: High Qulity Cold Roll Steel

    Structure: Knock down,easy assemble

    Lock: Safety lock and 3-point key lock

    Layer of each:bay 6 layers or customized

    Thickness: 0.8-2.5mm

    Surface: Electrostatic Powder Coating

    Spare parts: As your requirement

    Color: grey

    Zhijia Service:


    Solution: Available for free

    ODM&OEM:Available

    Certification:ISO90001/ISO14001

    Warranty:warranty 5 years

    Business Type:Manufacturer

    Advantage:Factory price

    Response time:30 mins


    Specification:


    Shelf bodyStand ColumnCold-roll steel1.5mmGB708
    Partition Whole body partition partition flange 25mm (reinforcing rib under the partition)Cold-roll steel1.0mmGB708
    Side plateCold-roll steel1.0mmGB708
    Upper cover plate (whole body side plate dimension 300X100mm)Cold-roll steel1.0mmGB708
    PanelCold-roll steel1.0mmGB708
    chassisMain beam and whole frame boardHot rolled steel plate3.0mmGB710
    (every wheelo frame board have six : 55mm beam bush hole. every hole have sealing
    pathwayRailHigh quality steel plateSolid square tubeGB710
    Rail boxHigh quality steel plate26X95mmGB710
    Thickness 3.0
    PathwayHigh quality steel plate50X185GB710
    Thickness 3.0
    Transmission partHandle crankZG45Bothway overload clutchGB1285
    double axis transmission
    Transmission shaftSolid core 45 steelΦ20GB699
    Linkage railSeamless steel tubeΦ20X2.5GB699
    BearingPrecision bearingHR6204GB/T
    307.3-2005
    Chain wheelZG45 GB1135
    ChainFR420Φ8.5, pitch12.7GB1244
    breaking force 1800kg
    Idler wheelHT20-40Cast ironGb11351
     Sealing rubber stripMagnetic fluid sealant
    Dust shieldCold-roll steel1Gb710
    BarbHot rolled steel plate3.0mmGb711


    Quality 3 Point Key Lock 6 Layers Moving File Cabinets Shelf System Corrosion Protection for sale
